NOTE: This distance is the MINIMUM distance to install the DET magnet.
The magnet can be placed at a greater distance but verify that it is not
outside the highest speed profile’s slowdown distance.
UET Magnet Placement
1. After placing the DET magnet in the correct location, run the car to
just above the newly placed magnet.
2. Turn on Dip Switch #2 (Dip A) and switch the car to Normal.
3. Go to MAIN MENU | SETUP | LEARN MODE COMMANDS | HOMING
RUN. Press enter and select YES.
4. When the car stops at the new DET position (IOs 511/512 = OFF)
press the left arrow button once and scroll down to MOVE TO
BOTTOM. Press enter and select YES.
5. When the car stops at the bottom door zone, turn Dip Switch #2
(Dip A) to OFF and enter a car call to the floor below the top
terminal landing.
6. From CT Inspection, run the car up just below the UET magnet and
remove it.
7. Run the car down to the next door zone below the terminal landing
and position the UET magnet on the tape opposite the DZ magnet.
8. Go to MAIN MENU | STATUS | MAGNETS | DZ MAGNET ## and
scroll to the floor the car is currently at. Record the TOP position
for the magnet.
Top: ____’ ____.____”
9. Run the car down to a door zone far enough below the magnet for
a full speed run.
