---CAR DOOR DATA----
DN [ | ] PI:25 T-14
GSW DCL ... .. .. ..
... ... ... .. DPM
---CAR DOOR DATA----
DN [ | ] PI:25 T-14
... ... DOL .. .. ..
... ... ... .. ...
Car Door Data Screen
These screens show the status of the door operator signals.
When the letters are visible the flag is being made.
Below are two examples of the car door status screen when Open and Closed:
Car Door Closed Car Door Open
--- CAR DOOR DATA ----
FIRST LINE
1. UP / DN – Direction of travel
2. [ | ] – Door status
3. PI: – Position Indicator
4. T-# / B+# – Magnet steps (only in door zone)
SECOND LINE
1. GSW – Gate Switch
2. DCL – Door Close Limit
3. DOL – Door Open Limit
4. DO – Door Open
5. DC – Door Close
6. ND – Nudge
THIRD LINE
1. DCB – Door Close Button
2. DOB – Door Open Button
3. PHE – Photo Eye
4. SE – Safety Edge
5. DPM – Door Position Monitor
FOURTH LINE
1. CAM – Door Cam
2. RES – Door Restrictor
3. RUN – Providing low current output to doors during travel
4. HVY – Used for heavy car/hall doors
DN [ | ] PI:25 T-14
16385 246’00.18”
CMD:-LEV FPM:-10
---CAR DOOR DATA----
DN [ | ] PI:25 T-14
GSW DCL DOL DO DC ND
DCB DOB PHE SE DPM
CAM RES RUN HVY
---HALL DOOR DATA---
DN [ | ] PI:25 T-14
BL BC ML MC TL TC
