Smartrise F220

16
Hall Door Data Screen
--- HALL DOOR DATA ---
FIRST LINE – SAME AS CAR DOOR DATA
SECOND LINE
1. BL / BC – Bottom Hall Lock / Bottom Close Switch
2. ML / MC – Middle Hall Lock / Middle Close Switch
3. TL / TC – Top Hall Lock / Top Close Switch
Door Status Descriptions
DOOR ICON
MEANING
[ | ]
Doors are fully closed
[ < > ]
Doors are opening
[ ]
Doors are fully open
[ > < ]
Doors are closing or nudging
[ < | > ]
Doors are opening but gate switch is still made
< >
Doors are fully open but the Door Open output is still on
[ | | ]
Doors are ajar or not flagging properly – Unknown status
Bottom Hall Door Open –
BL / BC not flagging
---HALL DOOR DATA---
.. .. ML MC TL TC
