Software provided by USB Flash Drive
Every Smartrise job is provided with a binder that consists of a USB Flash Drive containing
software for the specific job. Smartrise controllers are shipped with the software already
installed on the controller; this flash drive is provided as a back-up.
1. Insert the supplied USB Flash Drive into the laptop. Usually a menu similar to the one
shown below will appear. If no menu appears then open “My Computer” and click on the
Removable Disk drive.
2. Click on the “Open folder to view files” option to explore the Smartrise folders. A list of
folders with the software will appear. The software is located in the “(1) – Controller
Software” folder.
It is imperative that you install the correct software onto the correct JTAG port.
To do this, first connect your Smartrise programmer to your laptop via USB, and then connect
the other end to the JTAG port on the controller.
correspond to the JTAG
ports located on the
