Stationary Motor Auto-Tuning
1) Install a temporary jumper between H1 on the drive and REF on the
DIN rail.
2) Turn on the power to the drive. The initial display appears.
3) Press UP or DOWN arrow key until the Auto-Tuning display
appears.
4) Press ENTER key to begin setting parameters.
a) Press ENTER key to select the value for T1-01. Set to “1”
5) Save the setting by pressing ENTER.
6) The display automatically returns to the display shown in Step 3.
Verifying/Entering Data from Motor Nameplate
1) The drive comes pre-set with the customer’s motor data. When
performing the motor Auto-Tune, verify the following parameters
match current equipment and change if needed, otherwise, leave
the defaults:
2) After verifying the data listed on the motor nameplate, press UP
arrow key to confirm and get to the “Tuning Ready” message.
3) Press and hold down the M Contactor during the duration of the
Auto-Tune.
4) Press RUN to activate Auto-Tuning.
** Remove the temporary jumper from drive H1 to REF. **
Auto-Tuning finishes in approximately one to two minutes
“1” – Selects Stationary Auto-Tune for Induction Motor
Motor Rated Power (kW) = (Motor HP x .74)
Motor Rated Voltage (VAC)
Motor Rated Current (AMPS)
Motor Rated Frequency (Hz)
Number of Motor Poles (See RPM Table)
No-Load Motor Current (AMPS) Use 45% of T1-04
