Smartrise F220

66
Stationary Motor Auto-Tuning
1) Turn on the power to the drive. The initial display appears.
2) Press UP or DOWN arrow key until the Auto-Tuning display
appears.
3) Press ENTER key to begin setting parameters.
a) Press ENTER key to select the value for T2-01. Set to “1”
4) Save the setting by pressing ENTER.
5) The display automatically returns to the display shown in Step 3.
Verifying/Entering Data from Motor Nameplate
1) The drive comes pre-set with the customer’s motor data. When
performing the motor Auto-Tune, verify the following parameters
match current equipment and change if needed, otherwise, leave
the defaults:
T2-01
“1” – Selects Stationary Auto-Tune for PM Motor
T2-04
Motor Rated Power (kW) = (Motor HP x .74)
T2-05
Motor Rated Voltage (VAC)
T2-06
Motor Rated Current (AMPS)
T2-08
Number of Motor Poles (See Specification Table – Sheet: 01)
T2-09
Motor Speed (RPM)
T2-16
Encoder Pulses (PPR)
