KEB Motor Learn
NOTE: Smartrise programs the KEB drive with factory defaults to properly
communicate with the controller. After factory testing, customer motor data (from
customer’s EDF) is programmed into the drive to provide an easier “out of box”
installation.
Initial Start Up
The complete motor data must be learned with the automated learn function.
The Motor Learn function can be found under the Tune Parameters group from the
Programming menu (Home > Prog > Tune Parameters > LL01).
Begin the procedure by setting:
• Motor Tuning LL01 = Start
Follow the instructions on the LCD screen. The user is instructed to:
1. Disable the brake (turn off the BR and EBR breaker).
2. Set command to zero on the MR SRU board under MAIN MENU | SETUP
| SPEED AND SLOWDOWNS | INSPECTION SPEED – set to “0”.
3. On the controller press and hold inspection (speed + direction + enable
inputs) until completed.
The process should take 2-5 minutes and will emit a high pitched noise while the
drive measures various motor parameters.
If not performing the Encoder Synchronization, turn on BR and EBR
breakers and return the inspection speed to factory setting on the
controller.
SETUP OF THE MOTOR LEARN IS NOW COMPLETE!
