ADVANCED TROUBLESHOOTING
The following list of troubleshooting steps are to help with the startup and
smooth running of the drive.
STARTING OVER! (DEFAULTING DRIVE)
Sometimes parameters get changed (and forgotten) or certain functions that
should work are not working for no apparent reason. In this case, starting over
with factory defaults may solve these issues.
DEFAULT DRIVE TO FACTORY SETTINGS:
1. Go to US.03 and load the opposite configuration of what is shown:
(example: PM Gearless – load Induction Geared / for PM Geared load
Induction Gearless) and save. After this value is saved, go back and load the
correct type. This does a complete background default on the drive.
2. Go to US.03 and choose “Write Configuration to Drive”.
RELOAD OEM VALUES (PROGRAMMED BY SMARTRISE):
1. Go to US.05 and choose “Restore OEM Defaults”.
MOTOR NOISE / VIBRATION
1. Vibration:
a. Cut the KP (LC03, LC04) and KI (LC08, LC09) gains in half.
2. Noise:
a. Change LE.05 to 8 (PM)
MOTOR NOT RUNNING WHEN GIVEN COMMAND:
1. Check LI.01: Needs to be NPN for the drive to receive signals from
controller.
2. Verify that parameters LF.41 through LF.43 are set to correct values. Refer
to parameter sheet located in job binder for correct values.
US.03: Choose opposite drive configuration (PM > Induction / Geared > Gearless)
US.05: Write Configuration to Drive
Reload the original drive configuration using the previous (2) steps
Restoring Smartrise Defaults:
US.05: Restore OEM Defaults (To Reload Smartrise Settings)
