Snap-On Triton D8 User Manual

Scope Multimeter Optional Settings
122
Display Settings
The Display setting allows you to change the displayed value in the Vertical Scale
icon to your preference.
NOTE
This setting ONLY changes the value displayed in the Vertical Scale icon.
Display Full Scale
- displays the value of the entire (full) scale
Example (Figure 12-31): If the vertical scale is set to 1V, the value displayed
is 1V.
Figure 12-31
Display Per Division - displays the graduation value of the major scale divisions
Example (Figure 12-32): If the vertical scale is set to 1V, the value displayed
is 0.1V.
Figure 12-32

Snap-On Triton D8 Specifications

General

Operating System	Android
Display	8-inch touchscreen
Connectivity	Wi-Fi, Bluetooth
Battery Life	8 hours
Software Updates	Yes, via Wi-Fi
Warranty	1 year
