1250 Frequency Response Analyzer Menu Terms
CWB / 1250_Op / Issue 9 1-3
1.1 INTRODUCTION
The 1250 Frequency Response Analyzer measures the gain and phase characteristics
of the system under test, when stimulated by a known sinusoid. Ease of use is provided
by the touch-sensitive front panel keys. Many advanced features are incorporated,
making full use of microprocessor technology.
Standard interfaces allow full remote control. Readings can be stored for future
processing or fed to external recording devices. The instrument can be either free-
standing or rack-mounted. Diagrams showing the front and rear panels are shown at the
end of this Chapter.
Figure 1.1 - 1250 Frequency Response Analyzer
1.2 BASIC MEASURING SET-UP
Figure 1.2 - Basic Measuring Set-up
