Solartron 1250 - Function Key Summary

1250 Frequency Response Analyzer Facilities For More Complex Measurements
CHFR/1250/1 10-7
10.1.6 FUNCTION KEY SUMMARY
Soft Key Display Displayed Choices
ANGLE ANGLE [degree] CONVENTION [-180 to +180ant. clk] (Default State}
↑
CONVENTION [0 to 360 ant. clk} SELECT and
(SELECT and CONVENTION [-360 to 0 ant. clk} ENTER
ENTER either) CONVENTION [0 to 360 clkwise]
↓
ANGLE [radian] CONVENTION
[-π to +π ant. clk]
SELECT and
CONVENTION
[0 to 2π ant.clk]
ENTER
CONVENTION
[-2π to 0 ant.clk]
CONVENTION
[0 to 2π clkwise]
xω
n
MULTIPLY BY [unity] (Default State}
[jω]
SELECT and ENTER
[1/jω]
[jω
2
]
[1/jω
2
]
SCALE DIVIDE BY [unity] (Default State}
[a, b] SELECT and ENTER
[r, θ]
See Note 1.
[last result]
Note 1. If {a, b] or [r, θ] is selected, values for a and b,
or r and θ respectively must also be entered.
LIMIT LIMIT CHECK [off] (Default State}
[on a] SELECT and ENTER
[on b] See Note 2.
[on r]
[on θ]
[on log r]
Note 2. For any choice other than “off”, Upper and
Lower Limit values must be entered.
