DAW Control
HUI AND MCU COMMON FEATURES
This section describes functions that are common to both HUI and MCU protocols.
The AWS faders and Solos and Cuts panels can be switched between controlling the analogue audio signal path and the DAW
using the Focus switch – see below. The Motion Control Panel, Master Control Panel and Plug-in Editor always control the
DAW. The illustration above shows the DAW controller elements in ‘DAW Focus Mode’. The greyed-out areas indicate
analogue-only console elements.
V-Pots
Each channel contains a continuous rotary controller or ‘V-Pot’. The Plug-in editor has four additional rotary controls for
plug-in parameters.
Channel
Faders
Channel
Meters
Solo and
Cut
Panel
Plug-in Editor Master Control Panel Motion Control Panel
AWS 924-948 Owner’s Manual Page 4-7
