AWS 924-948 Operator’s Manual Appendices Page A-1
AWS Physical Specifications
Parameter Condition Value Unit Notes
Height To top of meter trim 925 mm
Height adjustment -0 +20 mm
Width 1,445 mm
Depth 873 mm
Weight Including both legs 108 Kg
Each leg 4 Kg
Heat dissipation: AWS 924 550 W
AWS 948 650 W
Voltage Input range 100 – 240 V ±10%
Current: Over voltage range: 7.5 – 3.1 A
Power factor 0.95
Fusing None
Noise Fanless
Connectors: Mains input IEC male
Serial 9-way D-type female
VGA Out HD 15-way D-Type (640 x 480 60Hz)
AWS Performance Specifications
Parameter Path Value Notes
Headroom <+27dBu 1kHz (<1% THD)
Frequency Response Microphone input – Insert Send ±0dB at 20 Hz
-0.08dB at 20kHz -4dB at 200kHz
Line input – Direct out ±0dB at 20 Hz
-0.08dB at 20kHz -3dB at 135kHz, -6dB at 195kHz
Line input – Track / Aux Bus out ±0dB at 20 Hz
-0.08dB at 20kHz -3dB at 135kHz, -6dB at 185kHz
Line input – Mix / Rec out ±0dB at 20 Hz
-0.08dB at 20kHz -3dB at 135kHz, -6dB at 185kHz
Noise Microphone input – Insert Send <-126dBu EIN 20Hz – 20kHz
Line input – Direct out <-89dBu 20Hz – 20kHz
Line input – Track / Aux Bus out <-89dBu No channels routed
<-80dBu All channels routed
Line input – Mix / Rec out <-89dBu No channels routed
<-84.5dBu All channels routed
THD Line input – Direct out 0.005% at 1kHz +24dBu, 80kHz Filter
Line input – Track / Aux Bus out 0.005% at 1kHz +24dBu, 80kHz Filter
Line input – Mix / Rec out 0.005% at 1kHz +24dBu, 80kHz Filter
