H: GLOSSARY OF TERMS
Analogue Focus Mode Channel faders control the channel audio; channel meters show analogue input levels.
C
hannel Rotary Encoders control DAW parameters.
B
ass Management A system designed to ensure that all the bass recorded on your DAW tracks is
reproduced correctly on the monitor speakers. Put simply, bass content below the
cutoff frequency of the main monitors is combined and fed to a subwoofer, thereby
effectively extending the response of the main outputs.
Channel V-Pot The rotary controls on the channel Solos and Cuts panels.
Console Focus Button The button on the Master Control Panel that looks like this:
It selects Analogue or DAW Focus Mode.
DAW Focus Mode Channel faders control DAW fader levels. Channel meters show DAW meter levels.
Channel Rotary Encoders are available for other DAW functions such as pan or send
controls.
Master Control Panel The panel below the screen and soft key area.
Master Send V-Pot The only knob on the Master Control panel – used to cycle through available sends.
Also incorporates a ‘push to flip’ function used to flip send levels from the rotary
encoders to the channel faders,
Plug-in Editor V-Pots The four rotary encoders below the TFT screen.
Track Busses Eight console-wide mono busses that can be used as feeds to your DAW inputs, as FX
sends, or pretty much anything else you can think of.
H: Glossary
AWS 924-948 Operator’s Manual Appendices Page A-23
