8. Operate the control panel of MSU, and perform the automatic white balance adjustment.
WHITE button → ON(lit)
After the adjustment is completed, the message "AWB : OK" is displayed.
9. Operate the control panel of MSU, and set as follows.
• ND5 button → ON (lit)
• MASTER GAIN → 12 dB
10. Operate the control panel of MSU, and perform the automatic white balance adjustment.
WHITE button → ON (lit)
After the adjustment is completed, the message "AWB : OK" is displayed.
OHB File Store
1. Operate the control panel of MSU, and set as follows.
(1) FILE button → ON (lit)
(2) Touch panel operation : [OHB File] → [OHB Store] → [Store]
After recording is completed, a message “OHB File Stored” is displayed.
Setting after adjustment
• Setting for MSU
MASTER GAIN → 0
