7-1-1. Structure of Paint Related Files
When STANDARD
is executed.
Factory-set value 0
Output to
hardware (*1)
Scen File
Refer to “File Item” (*2)
Refer to “File Item” (*2)
Lens File
• The following items can be stored, when lens extender setting is OFF:
- Flare R/G/B
- V Modulation Shading R/G/B/Master
- Auto Iris Gain
• When lens extender setting is ON:
- White R/B
- Flare R/G/B
- V Modulation Shading R/G/B/Master
- Auto Iris Gain
OHB File
• The following items can be stored of white shading:
- R/G/B for H SAW, H PARA, V SAW, V PARA 3D
• The following items can be stored of black shading
- R/G/B for H SAW, H PARA, V SAW, V PARA 2D
• OHB matrix
• ND offset
Reference File
(*1): The additional data of each file is sent to each circuit in the unit.
(*2): For items that can be stored in the scene file and the reference file, refer to “7-8. File Items”.
