Connector Name Connector/Cable
• SDI 1/2
• SDI-MONI
• TEST OUT
• PROMPTER/
GENLOCK
• PROMPTER 2
(BNC)
Plug, BNC (Part No.: 1-569-370-12) or
5CFB coaxial cable/ Recommendation made
by Fujikura
• AUDIO IN
CH1/CH2
• MIC 1 IN
(XLR type 3-
pin, Female)
XLR, 3-Pin Male (Part No.: 1-508-084-00)
or ITT Cannon XLR-3-12C or equivalent
RET CTRL
(6-pin, Female)
Plug, 6-Pin Male (Part No.: 1-560-078-00)
or HIROSE HR10-7PA-6P or equivalent
DC OUT
(4-pin, Female)
Plug, 4-Pin Male (Part No.: 1-566-425-11)
or HIROSE HR10A-7P-4P or equivalent
DC OUT
(2-pin, Female)
Power tap (OE) ANTONBAUER 33710 or
equivalent
INTERCOM 1/2
(XLR type 5-pin, Fe-
male)
XLR, 5-Pin Male (Part No.: 1-508-370-11)
or ITT Cannon XLR-5-12C or equivalent
DC IN
(XLR type 4-pin,
Male)
XLR, 4-Pin Female (Part No.:
1-508-362-00) or ITT Cannon XLR-4-11C
or equivalent, or Cable assembly
1-551-577-00 (Supplied with AC-550)
CRANE
(12-pin, Female)
Connector, Round Type 12-Pin (Part No.:
1-819-261-11)
REMOTE
(8-pin, Female)
• Plug, 8-Pin Male (Part No.:
1-766-848-11) or CCA-5 cable assem-
bly (CCA-5-10 (10 m) /CCA-5-3 (3
m)) (optional)
*1*2
• REMOTE cable (Part No.:
1-783-372-11) (supplied with RM-
B150, 10 m)
*1*2*3
TRACKER
(10-pin, Female)
Connector, Round Type 10-Pin (Part No.:
1-506-522-12)
1-2-4. Note in Connecting BPU Connector
It is recommendable to clean the optical contact portions
mentioned below before connecting this unit to the baseband
processor unit.
• BPU connector of this unit
• Camera connector of the baseband processor unit
• Optical/Electrical cable
For details on a cleaning method, refer to “2-4. Cleaning of
Connector/Cable”.
*1: If using a cable of length different from a standard product, contact your local Sony Sales Office/Service Center.
*2: The pin 8 of CCA-5 cable is GND (ground). The pin 8 of REMOTE cable is not GND (ground).
*3: Use of REMOTE cable enables to monitor video signals. (The pin 8 is available for the video signal line.) The down-converted SD
signal is output.
HDC4300
1-7
