Sony HDC4300 - DPR Block

DPR Block
1002
1001
1004
1005
1006
1014
1007
1008
1013
1009
1003
1015
1012
1012
1011
1010
No. Part No. SP Description
1001 A-1860-032-A s MOUNTED CIRCUIT BOARD, CN-3421
1002 A-2076-814-A s MOUNTED CIRCUIT BOARD, SW-1672
1003 A-2078-337-A s MOUNTED CIRCUIT BOARD, DPR-370
1004 A-8286-163-D s PAD ASSY,SHOULDER
1005 1-855-374-11 s DC FAN
1006 1-968-158-11 s HARNESS, SUB (FRONT MIC)
1007 2-433-598-01 s HOLDER (LT-11U), WIRE
1008 2-640-315-02 o SCREW (M2X5), SMALL, +P, SW
1009 3-853-802-01 s CLAMP,REUSE
1010 4-574-579-01 s SHEET (2.0 (38X38)), RADIATION
1011 4-533-878-01 s SHEET, RADIATION (L)
1012 4-382-854-51 s SCREW (M3X6), P, SW (+)
1013 4-559-446-01 s SCREW, +P2.6X5 LOCK ACE
1014 1-543-793-11 s FILTER, CLAMP (FERRITE CORE)
1015 4-542-018-01 s GASKET (10X10X15)
HDC4300
10-14
