Sony HDC4300 - Hotshoe Block

Hotshoe Block
K 2 x 5
K 2 x 5
B3 x 8
B3 x 8
1401
1402
1403
1404
1410
1410
1405
1405
1406
1407
1408
1409
1411
No. Part No. SP Description
1401 A-1842-424-A s HOTSHOE ASSY(AL)
1402 X-3704-670-2 s HOT DOOR
1403 1-968-152-11 s HARNESS, SUB (BUILD UP)
1404 3-626-781-03 s STOPPER
1405 3-872-522-02 s SPRING,COMPRESSION(STOPPER)
1406 3-872-550-02 s STOPPER(R),HOT DOOR
1407 3-872-551-02 s STOPPER(L),HOT DOOR
1408 3-872-573-02 s WATER PROTECT(HOT DOOR)
1409 4-382-854-51 s SCREW (M3X6), P, SW (+)
1410 4-559-446-01 s SCREW, +P2.6X5 LOCK ACE
No. Part No. SP Description
1411 4-654-273-02 s ACE (M2), LOCK [B2x5]
7-621-555-30 s SCREW +K 2X5
7-682-548-09 s SCREW +B 3X8
HDC4300
10-18
