1-5. Fixtures/Measuring Equipments List
1-5-1. Service Tools
Part No. Name Usage/Note
J-6029-140-B Pattern box PTB-500 Camera adjustment
J-6323-430-A Torque screwdriver’s bit (M3) Screw tightening
J-6325-110-A Torque screwdriver’s bit (M1.4) Screw tightening
J-6325-380-A Torque screwdriver’s bit (M2) Screw tightening
J-6325-400-A Torque screwdriver (3 kg•cm) (0.3•N m) Screw tightening
J-6252-510-A Torque screwdriver (6 kg•cm) (0.6•N m) Screw tightening
J-6252-520-A Torque screwdriver (12 kg•cm) (1.2 N•m) Screw tightening
J-6326-120-A Hexagon bit (For torque screwdriver) (size
1.5)
Screw tightening
J-6394-080-A Grayscale chart Transparent type (16 : 9), Camera adjustment
J-6480-010-A Alignment sleeve remover HC-001 For Female connector, DCC.91.312.5LA manufac-
tured by LEMO or equivalent
J-7120-950-A Chart adaptor Adaptor that installs ITE test chart (16 : 9) 310 X200
in PTB-500 (pattern box)
J-7120-960-A ITE STANDARD TEST CHART ITE resolution chart (16 : 9)
J-7120-970-A ITE STANDARD TEST CHART ITE grayscale chart (γ=0.45) (16 : 9)
J-7120-980-A ITE STANDARD TEST CHART ITE inmega cycle chart (16 : 9)
7-600-002-52 Locking compound (TB-1401B) Inhibits loosening of screws
Commercially available Loctite (408) Instant adhesives
Commercially available Grayscale chart Reflective type (16 : 9), Camera adjustment
Commercially available Star chart Reflective type, Camera adjustment
Commercially available USB memory Upgrading software, writing and rewriting the PLD
internal data
1-5-2. Measuring Equipment
Use the calibrated equipment or equivalent as listed below for the adjustments.
Equipment Name
Oscilloscope Tektronix TDS460A or equivalent
HD waveform monitor LEADER ELECTRONICS LV5150DA, LV5152DA or equivalent
Frequency counter Advantest TR5821AK or equivalent
Digital voltmeter Advantest TR6845 or equivalent
HD color monitor Sony BVM-D20F1J/D14H5J or equivalent
Luminance meter Konica Minolta LS-110 or equivalent
Spectrum analyzer Advantest R3131A or equivalent
Signal generator Tektronix TSG130A or equivalent
FM signal generator Rohde & Schwarz SMHU58 or equivalent
