Sony HDC4300 - DC in Connector (CN-3432 Board)

Procedure
1. Remove the two screws, and detach the REMOTE connector (CN-3430 board).
2. Disconnect the harness from the connector (CN1) on the REMOTE connector (CN-3430 board).
REMOTE connector (CN-3430 board)
B2.6 x 5
Harness
CN1
3. Install the removed parts by reversing the steps of removal.
4-11-5. DC IN Connector (CN-3432 Board)
Preparation
1. Remove the MIC panel assembly. (Refer to“4-11-1. CN-3429 Board/CN-3427 Board” on page 4-47 )
Procedure
1. Remove the two screws, and detach the DC IN connector (CN-3432 board).
2. Disconnect the harness from the connector (CN2) on the DC IN connector (CN-3432 board).
B2.6 x 5
DC IN connector (CN-3432 board)
Harness
CN2
3. Install the removed parts by reversing the steps of removal.
HDC4300
4-51
