Section 5
Electrical Alignment
When any board of this unit is repaired or replaced, adjust this unit for electrical adjustments as this section.
Note
• Perform the “5-4. Video System Level Adjustment” according to the system that the customer uses.
• Master setup unit MSU-1000/1500 is used for electrical adjustments of the unit.
Without using master setup unit (here after MSU), the electrical alignment also can be made using setting menu
of the camera.
Refer to “5-1-7. Setup Menu Correspondence List” for detail of setup menu.
5-1. Preparations
Turn on the external main power switch before starting adjustments, and warm up the unit for about 10 minutes.
5-1-1. Required Equipment, Tool
Note
Use calibrated equipment and tools.
Equipment Required
Name Equipment
HD waveform monitor Leader Electronics LV5150DA, Leader Electronics LV5152DA
(multi format) or equivalent
HD color monitor Sony BVM-D20F1J/BVM-D14H5J or equivalent
Oscilloscope Tektronix TDS460A or equivalent
Master setup unit Sony MSU-1000/1500
HD viewfinder Sony HDVF-20A/200/C30WR/C35W
Lens Canon HJ18 or equivalent
Tool
Name Sony Part No. Remarks
Grayscale chart (16 : 9 reflective type) — Commercially available
Since time degradation is appeared, re-
place for every two years. (The exchange
time, change by the safekeeping situa-
tion.)
Grayscale chart (16 : 9 transparent type) J-6394-080-A Use when the grayscale chart (16 : 9 re-
flective type) is not available.
Pattern box PTB-500 J-6029-140-B
5-1-2. File Data at Adjustment
The file structure of the adjustment data of this unit is as follows.
HDC4300
5-1
