OHB_ADJ1
<OHB-ADJ1> S05 TOP
1080-59.94i[4:2:2]
[R1][G1][B1]
GAIN_CONT: C7 A9 B1
[R2][G2][B2]
GAIN_CONT: C2 A2 A6
FILTER : ON
MONITOR SEL : YPbPr
STORE FILE : EXEC
The OHB_ADJ1 menu is used for adjustment of the CMOS block. For details, refer to “5-3-2. Sensitivity Adjustment”.
BLACK SHADING
<BLACK SHADING> S06 TOP
1080-59.94i[4:2:2]
[R] [G] [B]
V SAW : 01 00 03
V PARA : FF FF FE
H SAW : 00 00 00
H PARA : 01 01 02
BLK SET: 00 01 19
OFFSET: 01 00 FB
GAIN: 0dB
MONITOR SEL : YPbPr
STORE FILE: EXEC
The BLACK SHADING menu is used for adjustment of the black shading. For details, refer to the sections below.
• “5-3-1. Black Set Adjustment”
• “5-3-3. Black Shading Adjustment”
WHITE SHADING
<WHITE SHADING> S07 TOP
[R] [G] [B]
V SAW : F6 0F 06
V PARA : F6 F4 F5
H SAW : 0C FA 04
H PARA : FA F6 F7
WHITE : 0 0 0
STORE FILE: EXEC
COLOR_TEMP_SEL: 3200K
The WHITE SHADING menu is used for adjustment of the white shading. For details, refer to “5-3-2. Sensitivity
Adjustment”.
HDC4300
8-6
