6.7 Ventilation tube system
Standard tube systems are preconfigured for the various patient groups. If
other tube systems are used, make the appropriate settings in this menu or
in the System Settings/Sensors/Tube system menu (see chapter 4.2.4).
The corresponding tube system must be selected for this based on the
type designation or a pictogram.
If no new patient is displayed, the presetting for the tube system of the
last ventilation is adopted.
Fig. 76: Presetting for the patient tube system
FRITZ STEPHAN GMBH explicitly recommends that only patient tube systems included
in the list of accessories are used. Otherwise, ventilator function may be impaired!
If it is necessary to use a non-standardized tube system that has not been tested by
FRITZ STEPHAN GMBH, select the "Other Tube System" option. Then enter the tube
system's parameters manually.
