4.2.4 Ventilation tube system
Standard tube systems are preconfigured for the various patient groups. If
other tube systems are used, make the appropriate settings in this menu or
in the Ventilation Breathing System menu (see chapter 6.7). The
corresponding tube system must be selected for this based on the type
designation or a pictogram.
Fig. 56: Presetting for the patient tube system
Fritz Stephan GmbH explicitly recommends that only patient tube systems included in
the list of accessories are used. Otherwise, ventilator function may be impaired!
If it is necessary to use a non-standardized tube system that has not been tested by
FRITZ STEPHAN GMBH, select the "Other Tube System" option. Then enter the tube
system's parameters manually.
