1.9 Specifications
Operation
Temperature
−10 – 40° C
Relative humidity
5 – 95%
(non-condensing)
Air pressure
540 – 1100 hPa
Storage
Temperature
−20 – 50° C
Relative humidity
10 – 80%
(non-condensing)
Air pressure
540 – 1100 hPa
Store in a protected, dust-free location protected
from humidity.
Class according to
93/42/EEC
II b
Protection type
IP 44
Protection against contact with tools, conductive
parts with a diameter > 1.0 mm; protection
against foreign objects with a diameter > 1.0 mm
Protected against splash water from any
direction
UMDNS code
18-098
GMDN code
36289
Inspection/
maintenance cycle
Annually
Dimensions
(WxHxD)
360 x 320 x 155 mm
Weight
Main device without
external battery
6.3 kg
Main device with
external battery
6.9 kg
Sound pressure level
46 dB (A)
Sound power level
56 dB
Maximum pressure
limit
P
LIM,
max
100 mbar (SFC)
