1 General information
 Fritz Stephan GmbH
GA-070T-0518V2.7-HAO-EN
23
Mains
Connection
100 – 240 V AC
50 – 60 Hz
Protection class
II according to IEC 60601-1
Supply line
Power supply
Power consumption
Max. 150 W
Current consumption
1.667 – 0.625 A
Battery
Type
Lithium-ion
Nominal voltage
25.2 V DC
Nominal capacity
2.1 Ah
Operating time
(with optional external
battery)
(new batteries,
fully charged)
Max. 6 hours/
min. 3.5 hours
Battery 1 (internal)
Max. 3 hours
Battery 2 (external),
optional
Max. 3 hours
Charge time battery 1
Approx. 3 hours
Charge time battery 2
Approx. 4 hours
Batteries 1 and 2 are only charged at a battery
temperature of 0 – 40° C.
NOTE
The battery life of the ventilator is reduced at extreme temperatures.
Ambulance bracket
Dimensions
380 x 360 x 118 mm (W x H x D)
Weight
3.5 kg
Connections:
12 – 28 V DC
Energy supply
Brackets
