Non-invasive pressure-controlled synchronized intermittent 7.3.2.4
mandatory ventilation (nPC-SIMV)
The nPC-SIMV corresponds to the behavior of the PC-SIMV. It is only
available in non-invasive Neo mode. The device is operated without a
flow sensor (PNT) in this mode. The pressure is measured proximally via
the pressure measurement adapter set.
Ventilation mode
Adjustable parameters
nPC-SIMV
 O
2
 Inspiration time (Tinsp) and breathing frequency (f)
(the parameters for breathing cycling can be
configured, see chapter 4.4.2)
 Positive end expiratory pressure (PEEP)
 Ramp time
 Inspiration pressure (Pinsp)
 Trigger
 Flow limitation (in NEO mode only)
Tab. 26: nPC-SIMV
Ventilation mode
Adjustable parameters
nPC-SIMV
with PSV
 O
2
 Inspiration time (Tinsp) and breathing frequency (f)
(the parameters for breathing cycling can be
configured, see chapter 4.4.2)
 Inspiration pressure (Pinsp)
 Positive end expiratory pressure (PEEP)
 Ramp time
 Pressure support (Psupp)
(relative set value with reference to PEEP)
 Trigger
 Expiratory trigger sensitivity (ETS)
Tab. 27: nPC-SIMV with PSV
