7 Ventilation modes
154
GA-070T-0518V2.7-HAO-EN
 Fritz Stephan GmbH
Ventilation mode
Adjustable parameters
PC-SIMV
with PRVC
 O
2
 Inspiration time (Tinsp) and breathing frequency (f)
(the parameters for breathing cycling can be
configured, see chapter 4.4.2)
 Positive end expiratory pressure (PEEP)
 Ramp time
 Target volume (VT)
Tab. 24: PC-SIMV with PRVC
Ventilation mode
Adjustable parameters
PC-SIMV
with PSV
 O
2
 Inspiration time (Tinsp) and breathing frequency (f)
(the parameters for breathing cycling can be
configured, see chapter 4.4.2)
 Inspiration pressure (Pinsp)
 Positive end expiratory pressure (PEEP)
 Ramp time
 Pressure support (Psupp)
(relative set value with reference to PEEP)
 Trigger
 Expiratory trigger sensitivity (ETS)
Tab. 25: PC-SIMV with PSV
