Stephan EVETR - Non-Invasive Pressure-Controlled Assist;Control Ventilation (Npc-ACV)

®
7 Ventilation modes
 Fritz Stephan GmbH
GA-070T-0518V2.7-HAO-EN
157
NOTE
The PC-ACV ventilation mode can be used with volume guarantee (PRVC) (see
chapter 7.4.1). It also includes an option for tube compensation (see chapter 7.4.3).
Ventilation mode
Adjustable parameters
PC-ACV
with PRVC
 O
2
 Inspiration time (Tinsp) and breathing frequency (f)
(the parameters for breathing cycling can be
configured, see chapter 4.4.2)
 Positive end expiratory pressure (PEEP)
 Ramp time
 Target volume (VT)
 Trigger
Tab. 29: PC-ACV with PRVC
Non-invasive pressure-controlled assist/control ventilation (nPC-7.3.2.6
ACV)
The nPC-ACV corresponds to the behavior of the PC-ACV. It is only
available in non-invasive Neo mode. The device is operated without a
flow sensor (PNT) in this mode. The pressure is measured proximally via
the pressure measurement adapter set.
Ventilation mode
Adjustable parameters
nPC-ACV
 O
2
 Inspiration time (Tinsp) and breathing frequency
(f)
(the parameters for breathing cycling can be
configured, see chapter 4.4.2)
 Positive end expiratory pressure (PEEP)
 Ramp time
 Trigger
 Flow limitation (in NEO mode only)
Tab. 30: nPC-ACV
