7 Ventilation modes
148
GA-070T-0518V2.7-HAO-EN
 Fritz Stephan GmbH
Ventilation mode
Adjustable parameters
VC-SIMV
 O
2
 Inspiration time (Tinsp) and breathing frequency
(f)
(the parameters for breathing cycling can be
configured, see chapter 4.4.2)
 Positive end expiratory pressure (PEEP)
 Tidal volume (VT)
 Trigger
Tab. 18: VC-SIMV
NOTE
The VC-SIMV ventilation mode can be used with optional pressure support (PSV)
(see chapter 7.4.2). It also includes an option for tube compensation
(see chapter 7.4.3).
Ventilation mode
Adjustable parameters
VC-SIMV with
PSV
 O
2
 Inspiration time (Tinsp) and breathing frequency
(f)
(the parameters for breathing cycling can be
configured, see chapter 4.4.2)
 Positive end expiratory pressure (PEEP)
 Tidal volume (VT)
 Pressure support (Psupp)
(relative set value with reference to PEEP)
 Expiration trigger sensitivity (ETS)
Tab. 19: VC-SIMV with PSV
