12 Electromagnetic emissions and immunity
 Fritz Stephan GmbH
GA-070T-0518V2.7-HAO-EN
237
Immunity test
IEC60601 test level
Compliance level
Electromagnetic
environment guideline
Voltage dips, short
interruptions, and
voltage variations as
defined in
IEC 61000-4-11:2004
< 5% UT
(> 95% dip in UT) for
0.5 cycles
40% UT
(60% dip in UT) for
5 cycles
70% UT
(30% dip in UT) for
25 cycles
< 5% UT
(> 95% dip in UT) for
5 seconds
< 5% UT
(> 95% dip in UT) for
0.5 cycles
40% UT
(60% dip in UT) for
5 cycles
70% UT
(30% dip in UT) for
25 cycles
< 5% UT
(> 95% dip in UT) for
5 seconds
Mains power quality should be
that of a typical commercial or
hospital environment.
The battery run time specified
in the documentation must be
taken into account.
Power frequency
(50/60 Hz) magnetic
field as defined in
IEC 61000-4-8:2009
3 A/m
3 A/m
Power frequency magnetic
fields should be at levels
characteristic of a typical
location in a typical
commercial or hospital
environment.
UT is the A.C. mains voltage prior to application of the test level.
Tab. 51: Electromagnetic immunity (IEC 60601-1-2)
Immunity test
IEC60601 test
level
Compliance level
Electromagnetic environment
guideline
Portable and mobile RF communications
equipment should be used no closer to
any part of the EVE ventilator,
including the cables, than the
recommended separation distance
calculated from the equation applicable
to the frequency of the transmitter.
Conducted RF
disturbances as
defined in
IEC 61000-4-6
10 V
effective value
150 kHz to 80 MHz
outside ISM bands
a
10 V
effective value
Recommended separation distances:
Pd 35,0
Pd 2,1
Pd 6,0
for 80 MHz to 800 MHz
10 V
effective value
150 kHz to 80 MHz
in ISM bands
a
10 V
effective value
