3 Design and functional description
Pressing this button during inspiration will hold inspiration at the end of
the normal inspiration phase for the duration for which the button is
pressed (maximum 15 s). Pressing the button during expiration will
trigger a mandatory inspiration using the set ventilation parameters.
This function is not available for the CPAP, VCV and PRVC ventilation modes. The
key is then not illuminated.
This button lets you toggle the display, alarm indicator and
patient/function buttons between day and night mode.
Press the »Aerosol« button to switch on aerosol nebulization. The
medication nebulization duration can be set to between 5 and 30 min in
the "System Settings/Function" menu (see chapter 4.1.4). The
nebulization ends automatically at the end of the set time or when
pressing the button again. The button is green while nebulization is in
progress.
Aerosol nebulization is only possible if O
2
is connected to the ventilator.
Pressing the control knob for three seconds will lock the touchscreen.
Press the control knob again for three seconds to unlock the touchscreen.
When you tap the locked touchscreen, a lock icon appears in the
"System Settings" field (see chapter 3.2.7).
»Inspiration Hold«
button
»Day/Night« toggle
button
