3 Design and functional description
 Fritz Stephan GmbH
GA-070T-0518V2.7-HAO-EN
55
Item
Set 1
Set 2
Set 3
1
Pplat
(cannot be configured)
O
2
Pmean
2
VTe
VTe
VTe
3
MVe
EtCO2
VTespon
4
ftotal
SpO2
Ppeak
5
PEEP
Pulse
VTleak
Tab. 4: Basic configuration of the measured value indicator's three sets
With the exception of Pplat, the user can freely configure the type and
sort order of measured values in the three sets in the control panel
(see chapter 4.3.1). The measured values listed in the following table are
determined by the ventilator and can be displayed:
Category
Measured value
Description
Unit
Pressure
Ppeak
Inspiratory peak pressure
mbar
Pplat
Plateau pressure
mbar
Pmean
Mean airway pressure
mbar
PEEP
Positive end expiratory pressure
mbar
Volume
MVe
Expiratory respiratory minute volume
l/min
MVespon
Spontaneous expiratory respiratory minute volume
l/min
VTe
Expiratory tidal volume
ml
VTespon
Spontaneous expiratory tidal volume
ml
VTleak
Leak
ml
Flow
V´min
Minimum flow
l/min
V´max
Maximum flow
l/min
Time
Tinsp
Inspiration time
s
Texp
Expiration
s
ftotal
Total respiratory rate
(mechanical + spontaneous respiratory rate)
1/min
fspon
Spontaneous respiratory rate
1/min
I:E
Inspiration time ratio
-
