Still MX-X - Page 108

At operating hours
1000 h 2000 h 3000 h 4000 h 5000 h
6000 h 7000 h 8000 h 9000 h 10000 h
Carried
out

Drive wheel, wheel nuts or wheel screws and cushion tyre: check for secure attach-
ment.
Load wheels: check the condition and mounting and check for wear and foreign ob-
jects.
Load wheels: check for ease of movement.
Antistatic belt: check the condition.
Antistatic chain: check the condition.
Active load wheel axle
Function: check while driving in the aisle.
Measurement units: check the condition.
Measurement units: clean, remove any foreign objects.
Measuring rollers, sensors, magnets: check the condition.
Measuring rollers, sensors, magnets: clean, remove any foreign objects.
Spur gears: check the condition of the lubrication and relubricate if necessary.
Steering system
Steering: function check outside the aisle.
Steering: check the steering angle (>90° on both sides).
Steering: check straight line travel.
Steering gears: lubricate with all-purpose grease.
MZF: function check.
IZF: check for central positioning and accuracy of the guidance in relation to the
guide wire.
Steering angle measurement: check the level of play and the condition.
Steering knob, steering wheel: check for ease of movement.
Live ring bearings: check for ease of movement and wear.
Live ring bearings: check the play of the gears.
Steering motor bearings: check for operating noise.
Brake system
Service brake: check for correct function.
Reverse brake: check for correct function.
Drive unit: check the thickness of the brake lining and check the condition. Replace
if necessary.
Regular care and maintenance
5
1000-hour maintenance schedule
100 5231 804 2502 EN - 04/2020
