rubber buffers must rotate with the knurled-
head screws.
– Tension can be increased by screwing one
of the two knurled-head screws in further.
Tighten the knurled-head screws hand tight.
The battery lock is clamped securely if the
rubber buffer is clearly deformed.
– If sufficient clamping is not achieved via
these steps, it is possible that a battery with
incorrect dimensions has been inserted.
The truck must not be used if the battery is
not securely locked. Doing so would result
in the risk of accidents and damage.
– When the clamping has been carried out, a
thread must still be visible at (5) and (6).
Special equipment
7
Battery on a roller channel
124 5231 804 2502 EN - 04/2020
