Half of the display can be occupied by a mes-
sage window (1). This window is automatically
inserted from the right-hand side. The informa-
tion which was previously displayed centrally
is then shown in the left-hand section of the
display. The elements may sometimes over-
lap.
This message window has various content:
●
Messages relevant to operation
●
Messages with error numbers
●
Target position (drive order) and actual po-
sition for navigation
If the settings are modified, a special form of
the message window appears. This message
informs you that the changed settings are be-
ing saved. An acoustic signal accompanies
the display of this message. The message dis-
appears after four seconds.
Menu structure
The ten membrane switches can be freely
configured to display your favourite functions
on the main page. As soon as the button (7) is
actuated, the menu bar (1) opens. From this
point the structure is always the same. There
is also no change to structure when you select
a different language. The symbols also remain
the same.
The menu levels are as follows:
Industrial truck
(2)
Power-saving feature
Navigation
Lighting
(3)
Life height preselection
(4)
Used lift heights
Fans
(5)
Settings
(6)
Truck information
Production number
Display settings
Time
Date
Language
Status bar
Overview
3
Operating the display
34 5231 804 2502 EN - 04/2020
