Transportation safety device on glass
doors
Cab doors made of glass* are supplied with a
transportation safety device. This transporta-
tion safety device prevents the glass doors
from inadvertently opening during transporta-
tion and becoming damaged as a result.
– Remove and dispose of the transportation
safety device.
*Option
Mast bracing
Mast bracing may be required depending on
the configuration of the order picking truck.
Once the mast bracing has been installed, it
must be adjusted according to factory specifi-
cations and tightened to the specified torque.
The screw connection at the upper mounting
position on the mast bracing must be tight-
ened to 195 Nm.
The lower mounting position is marked with a
label. This label specifies the torque as
50 Nm
.
Operation
4
General commissioning
50 5231 804 2502 EN - 04/2020
