12-38 DF9.9T/TH “K8” (’08) MODEL
Positive +
harness
Positive +
PT relay lead wire
PT switch connector
(DF9.9TH)
Nut
Positive +
battery cable
Positive +
battery cable
Cap
Fuel hose
Caution lamp lead wire
PT switch lead wire
(DF9.9T)
PT switch lead wire
(DF9.9TH)
Clamp
Fix the lead wire and
fuel hose with clamp.
Negative
battery cable
PT relay lead wire
