DF9.9T/TH “K8” (’08) MODEL 12-39
Pulser coil
ground lead/Bolt
Main
wiring
harness
Cable tie
5 mm
or over
Cable tie
Clamp
Cable tie
Pulser coil
ground lead/Bolt
Main
wiring
harness
Cable tie
Clamp
DF9.9T
To Auto-enrichener
(PTC heater)
(R model)
DF9.9TH
Bolt
Tighten the bolt and
rectifier ground lead
wire together.
Ignition coil
Carburetor
Auto-enrichener
(PTC heater)
Pulser coil
Cable tie
CDI unit
Battery and condenser charge coil
Cable tie
Lead wire
