Chapter C Chapter C
Maintenance Mode
119
W301-0411E
[12
]:
Load ratio ( EN13000 spec.)
[13
]:
Outrigger state display
[14
]:
Maintenance mode display icon
[15
]:
Oil temperature 50°C icon
There is no display of 85°C icon.
[16
]:
Hook-in icon (Only for hook-in specification)
[17
]:
Tilt cylinder full retraction icon (Only for SACO-Jib specification)
[18
]:
Jib lock pin unlock icon
[19
]:
Boom elevation slow stop cancel icon
[20
]:
Swing angle
[
21]: Distortion voltage
[
22]: Elevating cylinder extension pressure
[
23]: Elevating cylinder retraction pressure
[
24]: Main pump pressure
[
25]: Error code display
[
26]: Indication showing that user adjustment is effective
[
27]: Indication showing that range limit setting is effective
[
28]: Indication showing that C/W setting is effective
[
29]: Indication showing that number of part lines setting is effective
[
30]: Indication showing that boom state setting is effective
[
31]: Indication showing that O/R state setting is effective
[
32]: Indication showing that <
> key is effective
[
33]: Indication showing that <
> key is effective
[
34]: Winch drum position (Only when winch drum position selection function is available)
(Refer to Chapter B 4.5 User Preset Menu and 7.4 Winch drum position selection.)
[
35]: 2nd boom length (Only for FAUN specification)
[
36]: Front jack
[
37]: Rear jack
[
38]: Boom telescoping type
[
39]: C/W mass (-0.1 t is displayed when there is no C/W)
C/W:（counterweight）
