Tadano AML-C User Manual

Chapter E Chapter E
Information and Data
181
W301-0411E
Item Adjustment condition
Adjustment value
( ): Tolerance at inspections
Power tilt jib
offset angle
(Zero/Span) Adjustment not needed
(Zero)
- Boom: Fully retracted
- Indicated boom angle: 80.0±0.1°
- Load: No load
(0.47 t main hook block only)
- Hook block: Twoblocking status
Actual hoist medium load
(Hook weight): 0.47±0.21 t
(Load radius)
- Boom: Full extended
- Load radius: 9.14 m
- Hoist medium load: 9.00 t
Load radius: 9.14±0.07m
Moment
(NOTICE 2)
(NOTICE 4)
(NOTICE 5)
(Span)
- Boom: Full extended
- Indicated boom angle: 20.0±0.1°
- Load: No load
(0.47 t main hook block only)
- Hook block: Hoist-down until just
before touching the ground
Actual hoist medium load
(Hook weight): 0.47±0.01 t
1.1.3 Slow Stop Adjustment
Item Remarks
Elevation up/down characteristics measurement Boom: Fully retracted
Swing control characteristics measurement
Boom: Fully retracted
Boom angle: Approx. 70°
Telescoping retraction characteristics measurement Adjustment not needed
1.1.4 Setting Item after Adjustment
Item Set value
Number of wire part-lines setting Main: 4; Aux.: 1
Language change English
Unit select ft/klbs
1.1.5 Option Setting
Item Set value
Telematics (alarm event)
In
(Adjustment not needed)
△
1
361-953-40100
