Tadano AML-C - Boom Lower Limit Stop; Boom Upper Limit Stop; Lifting Height Limit Stop; Load Radius Limit Stop

62
W301-0411E
Chapter B Chapter B
User Mode
6.1.4 Boom Upper Limit Stop
Restriction is implemented to the operations exceeding the boom angle that is set with the area limit.
Code at stop: W0026
Cancel: 100% stop cancel (Di6: ON)
Stop operation: (×: Stop operation)
M winch A winch
Boom
telescoping
Boom
elevation
Jib
telescoping
Jib tilt Swing
Jib
mounting
Up Down Up Down Ext. Ret. Rse. Lwr. Ext. Ret. Rse. Lwr. Right Left Ext. Stw.
×
6.1.5 Boom Lower Limit Stop
Restriction is implemented to the operations falling short of the boom angle that is set with the area limit.
Code at stop: W0027
Cancel: 100% stop cancel (Di6: ON)
Stop operation: (×: Stop operation)
M winch A winch
Boom
telescoping
Boom
elevation
Jib
telescoping
Jib tilt Swing
Jib
mounting
Up Down Up Down Ext. Ret. Rse. Lwr. Ext. Ret. Rse. Lwr. Right Left Ext. Stw.
×
6.1.6 Lifting Height Limit Stop
Restriction is implemented to the operations exceeding the lifting height that is set with the area limit.
Code at stop: W0028
Cancel: 100% stop cancel (Di6: ON)
Stop operation: (×: Stop operation)
M winch A winch
Boom
telescoping
Boom
elevation
Jib
telescoping
Jib tilt Swing
Jib
mounting
Up Down Up Down Ext. Ret. Rse. Lwr. Ext. Ret. Rse. Lwr. Right Left Ext. Stw.
× × × ×
6.1.7 Load radius Limit Stop
Restriction is implemented to the operations exceeding the load radius that is set with the area limit.
Code at stop: W0029
Cancel: 100% stop cancel (Di6: ON)
Stop operation: (×: Stop operation)
M winch A winch
Boom
telescoping
Boom
elevation
Jib
telescoping
Jib tilt Swing
Jib
mounting
Up Down Up Down Ext. Ret. Rse. Lwr. Ext. Ret. Rse. Lwr. Right Left Ext. Stw.
× × × ×
