4.4 Error Code Table
4.4.1 Communication Device Error (Transmitter, etc.)
- Crane operation
{: All the operations are possible.
¯: All the operations are stopped.
Port 1: Serial port connected with signal transmitter (for jib)
Port 2: Serial port connected with MDT (Multiplex Data Transmitter)
Error
code
Error name Description
Crane
operation
Serial port
transmission line 1
open
Notification is issued that the transmitter connected with port 1
cannot receive data from the AML. (Transmission break)
¯
E1001 Cause: Communication line from AML to transmitter is open. Radio wave interference, device
malfunction
Remedy: Check the wiring to the transmitter for conductivity. If no conductivity exists, replace or
repair the wiring. Replace the transmitter or AML’s power circuit board.
Serial port
transmission line 2
open
Notification is issued that the transmitter connected with port 2
cannot receive data from the AML. (Transmission break)
¯
E1002
Cause: Communication line from AML to transmitter is open.
Radio wave interference, device malfunction
Remedy: Check the wiring to the transmitter for conductivity. If no conductivity exists, replace or repair
the wiring. Replace the transmitter or AML’s power circuit board.
Serial port reception
line 1 open
The AML cannot receive data from the transmitter connected
with port 1. (Reception break)
¯
E1003
Cause: Communication line from transmitter to AML is open.
Radio wave interference, device malfunction
Remedy: Check the wiring to the transmitter for conductivity. If no conductivity exists, replace or repair
the wiring. Replace the transmitter or AML’s power circuit board. Replace the serial port
fuse of AML.
Serial port reception
line 2 open
The AML cannot receive data from the transmitter connected
with port 2. (Reception break)
¯
E1004
Cause: Communication line from transmitter to AML is open.
Radio wave interference, device malfunction
Remedy: Check the wiring to the transmitter for conductivity. If no conductivity exists, replace or repair
the wiring. Replace the transmitter or AML’s power circuit board. Replace the serial port
fuse of AML.
Transmitter 1 defect
Transmitter connected with port 1 has detected an internal
abnormality.
¯
E1005
Cause: Transmitter malfunction. Refer to transmitter repair manual.
Remedy: Replace the defective transmitter.
