Tadano AML-C User Manual

Chapter D
Chapter DAdjustment mode
172
W301-0411E
D-4 Performance Setup
<Performance setup menu>
When "Set up performance" is selected in the adjustment main menu of Fig. 1.3.3, the set up performance
screen appears as shown in Fig. 4.1.1. Pressing the <
> key (scroll up) or the < > key (scroll down) changes
the selected item (highlighted) in the set up performance menu. With the setup menu selected, pressing the
<
> key starts the selected menu. To go back to the adjustment main menu, press the < > key.
Fig. 4.1.1 Set up performance menu screen
4.1 Winch drum position selection
When "Winch drum position select" is selected in the set up performance menu of Fig. 4.1.1 and the < > key
is pressed, the winch drum position select screen is displayed as shown in Fig. 4.1.2 according to the
specification selection flag of winch drum position adjustment value selection (#17200-36).
Fig. 4.1.2 Winch drum position select screen
(Selection: front ←→ front / rear)
Winch drum position select
winch drum front / rea
r
winch drum front
