Foreword
ii
W301-0411E
2. Table of Contents
Foreword
1. Applicable Crane Model / Spec. No................... i
2. Table of Contents...............................................ii
3. Acronyms and Abbreviations ............................iv
4. International Standard ...................................... v
5.Crane Performance .........................................vii
6.Reduction of Rated Capacity.......................... viii
Chapter A
(Component of AML System)
A-1 Components of the AML System ............... 1
A-2 Input/Output Signals
of the AML System ....................... 11
2.1 AML Control Unit (Pin Assignment)
CN1 – CN9
Chapter B
(User Mode)
B-1 Functions and How to use
the User Mode.............................. 26
B-2 Registration of Operating State and AML
Function Check ............................ 28
B-3 Alarm and Recovery Operation ............... 38
3.1 Type of Warning Codes and Buzzer .. 38
3.2 Warning Code and Crane Model
Comparison Table ........................ 39
3.3 Warning code and Remedy List......... 40
B-4 Other Functions ....................................... 43
4.1 Working Range Limit Function........... 43
4.2 TARE Function................................... 49
4.3 Mute Alarm Function.......................... 49
4.4 Fuel Consumption Indicator............... 50
4.5 User Adjustment Menu ...................... 51
B-5 Action against AML System Error ............ 58
B-6 Do Output Control.................................... 59
6.1 Cause for AML Automatic Stop
Output .......................................... 59
6.2 Do Output Abnormality Processing.... 64
6.3 Drum Indicator Control Function........ 65
6.4 Output of warning .............................. 66
B-7 AML Control............................................. 67
7.1 Backward Stability Stop Function ...... 67
7.2 Working Range Limit Stop Function .. 67
7.3 Output of Interference Prevention
Warning .................................. 70
7.4 Winch Drum Position Selection
Function ....................................... 71
B-8 Proportional Control Function.................. 75
B-9 AML Cancel Function .............................. 76
Chapter C
(Maintenance Mode)
Outline of Maintenance Mode......................... 80
C-1 Operation Keys and Menu....................... 81
C-2 Individual Main Menu Functions .............. 85
C-3 Integrated Information Display Screen ...117
C-4 Error Code ............................................. 122
4.1 Classification of Error Code ....................122
4.2 Error History............................................122
4.3 Error Notification .....................................123
4.4 Error Code Table .....................................124
4.5 CPU State Indicator LED ........................133
C-5 Required Adjustment after AML System
Part Replacement ...................... 134
C-6 Disassembly and Assembly................... 135
