Chapter D
Chapter DAdjustment mode
160
W301-0411E
2.4.3 Swing Angle 1 Span Adjustment
- By the right (clockwise) swing operation, set the swing angle to the over-rear.
- Until "Swing Angle1" and "Span adjustment value" become highlighted on the LCD (Fig. 2.1.1), press the
<
> key (backward) or the < > key (forward).
Value ZERO SPAN
Swing Angle1 [°] 179.2
0.0 180.0
Detected swing angle 1 Span adjustment value
- Operate the <
> key (-) and the < > key (+) so that the detected swing angle 1 becomes the span
adjustment value. When the adjustment angle is reached, press the <
> key to register the adjustment
value.
After the adjustment value is registered, "
" is shown at the left of span adjustment value.
2.4.4 Swing Angle 2 Span Adjustment
- Keep the swing positions same as 2.4.3.
- Until "Swing Angle2" and "Zero adjustment value" become highlighted on the LCD (Fig. 2.1.1), press the
<
> key (backward) or the < > key (forward).
Value ZERO SPAN
Swing Angle2 [°] 180.8
0.0
180.0
Detected swing angle 2 Span adjustment value
- Operate the <
> key (-) and the < > key (+) so that the detected swing angle 2 becomes the span
adjustment value. When the adjustment angle is reached, press the <
> key to register the adjustment
value.
After the adjustment value is registered, "
" is shown at the left of span adjustment value.
2.4.5 Adjustment Check
- Set to the zero adjustment condition again.
- The adjustment is completed when the detected swing angle 1 and 2 are within the standard tolerance.
If the value is out of the standard tolerance, perform the zero adjustment and span adjustment again.
To Next Page
