3. Acronyms and Abbreviations
The following list contains some of the acronyms and
abbreviations used in this manual.
AML: Load Moment Indicator
AML override: Refer to Chapter B-9
Actuator: A mechanical device which converts
supplied energy into mechanical work
(Ex. hydraulic motor, hydraulic cylinder)
Ai: Analog Input
A/D conversion: Analog/Digital conversion
Ao: Analog Output
Aux.: Auxiliary
ASME: American Society of Mechanical Engineers
CAN: Controller Area Network (SAE1939)
CHG: Charge
CPU: Central Processing Unit
C/W: Counter weight
D/A: Digital/ Analog conversion
DCU: Display Control Unit (Meter controller)
Di: Digital Input
Do: Digital Output
Eco mode: Environmental communication mode
ECU: Engine Control Unit
FET: Field-effect Transistor
F.B.: Feed back
Fig.: Figure
Flash memory:
A Semiconductor memory device which can
be electrically erased and rewritten.
FMI: Failure Mode Identifier
FLJ: Full auto Luffing Jib
F/J: Front Jack
F/R: Front Right
F/L: Front Left
ICF: Information Controller for Telematics
ID: Identification
ISO: International Organization for Standardization
J/S: Joystick
LCD: Liquid Crystal Display
LED: Light Emitting Diode
MDT: Multiplex Data Transmitter
MMT: Moment
OE: Output Enable signal
(Fail-safe is active when the signal is ON.)
O/R: Outrigger
PC: Personal Computer
Pi: Pulse input
Pin Assignment:
Assignment of signals to the pins of
connectors
PT: Power Tilt
PTO: Power Take-off
RAM: Random Access Memory
ROM: Read Only Memory
rpm: Revolution per minute
RY: Relay
R/J: Rear Jack
SAE: Society of Automotive Engineers
Si: Serial input
SOL: Solenoid
SPN: Suspect Parameter Number
(Data Classification Number)
STM: Signal Transmitter (D, E type)
SW: Switch
S/T: Single Top
Tr: Transistor
T/C: Torque Converter
T/M: Transmission
USB: Universal Serial Bus
VCU: Vehicle Control Unit (node)
WDT: Watched dog timer
3S: 3 Second
20ms: 20 millisecond (20/1000 second)
Rated capacity = Max. Hoist medium load
Hoist medium load = _Net load + Hook Assy
_Net load = Payload + Sling
