60
W301-0411E
Chapter B Chapter B
User Mode
6.1.1 100% Lifting Performance Stop
When the load moment ratio (load ratio) exceeds 100%, the operation in the load ratio-increasing direction is
stopped. However, for the main boom operation with jib, the automatic stop is performed when the load
moment ratio (load ratio) becomes as follows:
(#20803)
Outrigger extension width Output
GR-750XL-2 GR-1000XL-2 GR-750XL-2 GR-1000XL-2
Maximum extension 7.3m 88% or more 94% or more
Middle extension 2 6.7m 87% or more 93% or more
Middle extension 1 5.5m 80% or more 92% or more
Main boom with jib judgment: (1) and (2)
(1) Jib extension detection is in "extension" status (Di7: OFF).
(2) "Boom operation" is set with AML.
Code at stop: W0023
W0124 (For the main boom with jib)
Cancel: 100% stop cancel (Di6: ON)
Stop operation: (×: Stop operation)
M winch A winch
Boom
telescoping
Boom
elevation
Jib
telescoping
Jib tilt Swing
Jib
mounting
Up Down Up Down Ext. Ret. Rse. Lwr. Ext. Ret. Rse. Lwr. Right Left Ext. Stw.
× × × × × × ×
Special note: The load ratio exceeds 100% when the boom raising stroke end is reached.
Therefore, when the boom angle is A° or more, the automatic stop will not be performed for the boom
lowering operation even when the load ratio is 100% or more.
(#2782)
GR-750XL-2 GR-1000XL-2
Angle A°
80.1 80.1
