Tadano AML-C User Manual

Chapter A Chapter A
Components of AML System
13
W301-0411E
CN2-1 connector SW status in AML
Pin No. Name
(Data No. #---)
Signal names and functions
ON (0) OFF (1)
10 Di10+
(#17202-2)
- Signal name: Main hoist-down detection
Detects the main winch hoist-down operation.
No operation Operation
11 Di11+
(#17202-3)
- Signal name: Auxiliary hoist-up detection
Detects the auxiliary winch hoist-up operation.
No operation Operation
12 Di12+
(#17202-4)
- Signal name: Auxiliary hoist-down detection
Detects the auxiliary winch hoist-down operation.
No operation Operation
13 Di13+
(#17202-9)
- Signal name: Boom extension detection
Detects the boom extending operation.
No operation Operation
14 Di14+
(#17202-10)
- Signal name: Boom retraction detection
Detects the boom retraction operation.
No operation Operation
15 Di15+
(#17202-11)
- Signal name: Boom raising detection
Detects the boom raising operation.
No operation Operation
16 Di16+
(#17202-12)
- Signal name: Boom lowering detection
Detects the boom lowering operation.
No operation Operation
17 Di17+
(#17202-17)
- Signal name: Swing right detection
Detects the swing operation to the right.
No operation Operation
18 Di18+
(#17202-18)
- Signal name: Swing left detection
Detects the swing operation to the left.
No operation Operation
19 Di19+
(#17206-41)
- Signal name: Outrigger emergency setting
Detects the selection of outrigger emergency setting.
Normal
setting
Emergency
setting
20 Di20+ (Spare)
